WTD RTXM320-571

Home > OEM > WTD >

WTD 40G 300m 850nm MM QSFP+ Transceiver Module

Alternative Views:

Our Price: $280.00

Warranty: 1 Year Warranty
Availability: In Stock
Leadtime: Usually ships within 2 Business Days

Product Code: RTXM320-571

Qty:

Description

This WTD RTXM320-571 is designed for fiber communication based on optical-electrical technology. The product is an integrated module containing a micro-optic component and semiconductor material. The module could implement optical-electrical conversion and electrical-optical conversion function. It could be used at key locations in optical networks like 40GBASE Ethernet.

Features

Up to 10.5Gb/s data rate per channel
Distance up to 300m on OM3 MMF and 400m on OM4 MMF
850nm VCSEL array transmitters
With Tx Power Monitoring
Single 1x12 MPO receptacle optical interface
Single +3.3V power supply
XLPPI electrical interface
Maximum power dissipation<1.5W
International Class 1 laser safety certified
Operating temperature range: 0°C ~ +70°C
Compliant with RoHS6

Applications

40GBASE-SR4 Ethernet

Standards

Compliant with QSFP+ MSA(SFF-8436 v3.4)
Compliant with SFF-8472 v10.2
Compliant with IEEE 802.3ba

Specifications

Part Number: RTXM320-571
Form Factor: QSFP+
Data Rate: 42G
Laser: 850nm VCSEL
Optical Power: -7.6 ~ -1dBm
Detector: PIN
Sensitivity: <-9.9dBm
Reach: 300m
DDM: Supported
Operating Temperature: 0 ~ 70°C
