25 Gigabit Dual Port SFP28 Intel E810-XXVAM2-BASED Low
Latency Ethernet Network Interface Card
This dual-port 25Gb network interface card (NIC) is
optimized on Intel E810-XXVAM2 controller for server connectivity and network
virtualization. By supporting a PCIe 4.0 x 8 host interface, this adapter
provides sufficient bandwidth for line rate traffic on dual 25Gb ports.
Improved support for virtualization, including VMDq and
SR-IOV, makes the NIC a perfect fit for virtualized environments. It is
designed to provide broad interoperability, critical performance optimizations,
and increased agility for communications, cloud, and enterprise IT network
solutions.
Product Highlights
PCIe 4.0 x 8 Host Interface and 25GbE Dual-Port
Transmission
Support both iWARP and RoCEv2 RDMA for low-latency,
high-throughput workloads
Dynamic Device Personalization (DDP) Increases Packet
Processing Efficiency
Data Plane Development Kit (DPDK) Optimized for
Efficient Packet Processing
Unified Networking Delivering LAN, iSCSI, NFS and FCoE
in One Low Cost CNA
Support Network Virtualization Offloads Including
SR-IOV, Geneve, VXLAN and NVGRE
Specifications
Controller
Intel E810-XXVAM2
Supported Ethernet Speeds
25/10/1GbE
Cabling Type
SFP28 Transceiver, DAC and AOC
OS Support
Windows, Linux, VMware, FreeBSD
Bracket Height
Tall & Short
Max. Power Consumption
20.8W
Storage Humidity
90% max. non-condensing relative humidity at 35ºC
Storage Temperature
-40 °C to 70 °C (-40 °F to 158 °F)
Operating Humidity
85% max. non-condensing relative humidity
Operating Temperature
0 °C to 55 °C (32 °F to 131 °F)
Card PCB Dimensions (WxD)
5.91x2.52" (150x64mm) (without bracket)
