The Netgear GSM4230UP-100NAS is a 24-port Gigabit Ethernet managed switch from the AV Line M4250 series, specifically engineered for 1G AV over IP applications, featuring 24 PoE++ (90W) ports with a 1,440W total budget, 4 SFP uplink ports, L2/L3/L4 management, and dedicated AV features like AVB support (with optional license) and pre-configured AV profiles for easy deployment.

Key Specifications:

• Product Name: M4250-26G4F-PoE++ (GSM4230UP)
• Port Configuration:
• 24 x RJ45 Gigabit Ethernet with PoE++ (90W/port)
• 4 x SFP Gigabit Ethernet Uplinks
• PoE Power:
• Total PoE Budget: 1,440W
• Power per Port: Up to 90W (802.3bt Type 4)
• Switching Performance:
• Switching Bandwidth: 60 Gb/s
• Forwarding Rate: 44.64 Mpps
• Management:
• Fully Managed Layer 2, Layer 3, Layer 4
• Web-based management GUI, console, telnet, SSH
• Pre-configured AV profiles and dedicated AV interface
• Specialized Features:
• AVB (Audio Video Bridging) Support: Yes, requires separate license activation
• NETGEAR IGMP Plus™: Enhanced IGMP for multicast
• Auto-Trunk and Auto-LAG for seamless connection with other M4250/M4300 switches
• Jumbo Frame Support (up to 12kb)
• Hardware & Physical:
• Rack Mountable: Yes, 1U size
• Form Factor: Rear-facing ports for clean AV rack integration
• Cooling: Fan/Passive combo with a 34 dB noise level
• Included Accessories: Power cords, console cables (USB-C & RJ45), rack-mount brackets, rubber footpads

Ideal Use:
This switch is designed for professional AV installers and integrators who need to deploy 1G AV over IP systems, providing high power delivery, essential AV networking features, and a clean, integrated solution within an equipment rack.

Compatible Transceivers

The NETGEAR GSM4230UP-100NAS (M4250-26G4F-PoE++) is a managed AV Line switch that comes with four 1 Gigabit SFP ports for fiber uplinks. The SFP ports support 1 Gigabit transceivers.
