Genuine Ruijie 10G SFP+ ER 1550nm 40km LC SMF DDM Transceiver Module
Genuine Ruijie XG-SFP-ER-SM1550

Alternative Views:
Our Price: $290.00
Warranty: 1 Year Warranty
Availability: In Stock
Leadtime: Usually ships within 2 Business Days


Product Code: XG-SFP-ER-SM1550
Qty:

Description

The Ruijie XG-SFP-ER-SM1550 is a high performance and cost effective SFP+ transceiver module supporting data-rate of 10.3125Gbps (10GBASE-ER) or 9.953Gbps (10GBASE-EW) over single mode optical fiber. The SFP+ transceiver module fully complies with SFP+ Multi-Source Agreement (MSA) standards SFF-8431, SFF-8432 and IEEE 802.3ae 10GBASE-ER/EW. Additionally, this SFP+ transceiver module also provides a unique enhanced digital diagnostic monitoring interface(DDMI) per SFF-8472, which providing real-time monitoring of the transceiver optics temperature, laser bias current, optical power, received optical power and transceiver optics supply voltage. The transceiver is a Class 1 laser product complies with FDA/CDRH and IEC-60825 standards.

Features
  • Genuine Ruijie XG-SFP-ER-SM1550
  • Electrical interface compliant to SFF-8431
  • Compliant with SFF-8472
  • 10Gb/s serial optical interface compliant to 802.3ae 10GBASE-ER
  • 1550nm EML transmitter, PIN photo-detector
  • Distance up to 40km on single mode fiber
  • LC Duplex connector
  • Built-in digital diagnostic functions
  • Single 3.3V power supply
  • Metal enclosure, for lower EMI
  • ROHS compliant and lead-free

Applications
  • 10GBASE-ER/10GBASE-EW Ethernet
  • 10G Fiber Channel
  • 10GbE Data Center Switches and Routers

Specifications
  • MFGR: Ruijie
  • Part Number: XG-SFP-ER-SM1550
  • Form Type: SFP+
  • Speed: 10Gb/s
  • Connector: Duplex LC
  • Media: SMF
  • Wavelength: 1550nm
  • Max Cable Distance: 40km
  • Optical Components: EML 1550nm / PIN
  • Transmitter Power: -2 ~ 3 dBm
  • Receiver Sensitivity: < -16 dBm
  • Digital Diagnostic Monitoring: Yes
  • Operating Temperature: 0 to 70°C (32 to 158°F)
  • Compliance: IEC/EN 61000-4-2,IEC-60825, FDA 21CFR 1040.10 and 1040.11, RoHS
